产品中心

800W HYDRAULIC OIL PUMP DC MOTOR GENERAL SPECS.Voltage 24V DCNo-Load Speed  4400RPMNo-Load Current < 3.5ARated Output Speed 3100RPMRated Output Torque 2.45N.mRated Output Power 800WRated Current < 60AInsulation Class FDuty cycle S2 - 2min.Customized shaft & front cover available upon requestApplication: AGV, Automobile cab steering, Rising-lowering lifting system, Electric forklift, Lifting pump station, Hydraulic power leveling system etc.

Heavy Truck Tarp Motor ( Tipper Sheeting Motor, Dura-Torque Gearmotor, Durabuilt Motor), Front to Back Power Tarp Motor, Rollover Power Tarp Motor, Voltage: 12V DC (or 24V DC )Rated Speed 20RPMRated Torque 100N.m @Current 31AMax. Efficiency 59%  @ 60N.m, 23RPM, Current 20AWith a Power-Off BrakeOperation Mode S2Reducttion Ratio: 70 : 11 inch Hollow Shaft  ( Solid shaft available upon request )



                Tarp Gear Motor w/Chrome CoverDump Truck Tarp Motor ( Tipper Sheeting Motor, Dura-Torque Gearmotor ), fits most automatic tarps systems.MOTOR SPECS AND FEATURE (GEAR RATIO 60:1): 3 years warrantyHi-torque, direct drive 12VDC (or 24VDC) motor (output torque is . lbs.)60:1 gear ratio.60 RPM (+/-6RPM)Power 600W ( L=246mm ) or 900W ( L=276mm, Model 80ZYTS-12/JW-3 )Epoxy sealed gearbox maintains lubrication.3-1/8" x 3/4" extended output shaft fits wide range of tarp systems.Sealed drive shaft and encased bearing prevents contamination.Chrome/plastic cover and fasteners included.100% tested for quality control.MOTOR SPECS AND FEATURE (GEAR RATIO 90:1):3 years warrantyHi-torque, direct drive 12VDC (or 24VDC) motor (output torque is. lbs.)90:1 gear ratio.40 RPM (+/-5RPM)Power 600W ( L=246mm ) or 900W ( L=276mm, Model 80ZYTS-12/JW-3 )Epoxy sealed gearbox maintains lubrication.3-1/8" x 3/4" extended output shaft fits wide range of tarp systems.Sealed drive shaft and encased bearing prevents contamination.Chrome/plastic cover and fasteners included.100% tested for quality control.Replaces Aero Power Plus, Donovan #61G/61L, Roll-Rite #1030/1031, US Tarp #11521/13655 and others

BRUSHED DC MOTOR   The bruhsed DC motors fit most Electric Wheelchairs & Power Wheelchairs   THE BRUSHED DC MOTORS SPECS AND FEATURE: ·  Motor Size: 71mm, 74mm, 80mm, 82mm, 84mm, 92mm, 100mm ·  Power: 100W, 150W, 200W, 250W, 300W, 350W, 400W, 450W ·  2 Poles, 4 Poles ·  12V DC ~ 36V DC ·  Speed 800 ~ 5000rpm ·  Operation Mode S1 ·  Without/with Brake

Tarp Gear Motor with Chrome CoverDump Truck Tarp Motor ( Tipper Sheeting Motor, Dura-Torque Gearmotor, Durabuilt Motor), fits most automatic tarp systems.MOTOR SPECS AND FEATURE (GEAR RATIO 90:1): 3 year warrantyHi-torque, direct drive 24VDC (or 12VDC) motorNo-load current 7A @ no-load speed 69rpmMaximum Efficiency 42%59rpm @ Max. efficiency 45N.m ( 390 in-lbs ) @ Max. efficiencyOutput Power 278W @ Max. efficiencyEpoxy sealed gearbox maintains lubrication. Sealed drive shaft and encased bearing prevents contamination.Chrome/plastic cover and fasteners included.100% tested for quality control.Replaces Donovan #& Roll-Rite #1031/10310 tarp gear motors.

APPLICATIONS: ·  Automatic Sliding Gate, Sliding Gate Operator, Gate Opener.   MOTOR SPECS & FEATURE ·  Motor OD Size: 76mm, 80mm, 83mm ·  Voltage: 12V DC, 24V DC, 36V DC, 48V DC ·  Power: 80W, 100W, 110W, 120W, 150W ·  Output Speed: 1500rpm / 1800rpm / 2500rpm / 2800rpm / 3000rpm / 3600rpm ·  Built-in brushes or external brushes ·  Without Gearbox ·  Customized shaft & front cover available upon request

180N.m POOL COVER GEAR MOTOR 80ZY/80JXZ TYPICAL SPECS.:Voltage 24V DCRated Speed 5rpmRated Torque 120N.m for Continuous Running ( 180N.m for Intermittent Running )With Brake and Managetic Encoder ( or Limit Switch )Stainless Steel Shaft SS316Compact & Large Torque Gearbox Ratio 308/1

 APPLICATIONS·  Solar Tracking Motor, Solar Tracker Motor etc.MOTOR SPECS & FEATURE·  Motor Type: Brushed DC Motor·  Motor Size: 60mm, 63mm, 70mm, 76mm, 80mm·  Voltage: 6 ~ 300V DC·  Ambient Temperature: - 40 ~ + 70 Degr. ·  IP 44, IP54, IP55 or IP65·  With/without Planetary Gearhead·  With/without Encoder

BRUSHED DC RIGHT ANGLE GEAR MOTOR / DOOR GEARED MOTOR ·  The brushed DC right angle gear motor fits parts of automatic garage doors, garage door openers, elevator doors.   BRUSHED DC RIGHT ANGLE MOTOR SPECS AND FEATURE: ·  Motor Size: 61MM OD ·  Power: 25W ·  Voltage 24V DC ·  Max. Current 10A ·  Max. Torque 20N.m ·  Max. No Load Speed 46RPM ·  Rated Speed 40RPM ·  Rated Torque 6N.m ·  Reduction Ratio 69 : 1 ·  With / Without Encoder     ·  Motor Size: 70MM OD ·  Power: 90W ·  Voltage 24V DC ·  Max. Current 8.0A ·  Max. Torque 20N.m ·  No Load Speed 230RPM ·  Rated Speed 180RPM ·  Rated Torque 5N.m ·  Reduction Ratio 17.5 : 1

DC RIGHT ANGLE GEAR MOTOR   DC Right Angle Gear Motor fits most electric wheelchairs & power wheel chairs   GEARMOTOR SPECS AND FEATURE: No Load Speed 130+/-5RPM No Load Current 4.89+/-5% A Rating Torque 6.78N.m Rating Power 145W Rating Current 9+/-5% A Max Effic. 70%
